Pneumatic Factory HV Series Hand Lever 4 Ports 3 Position Control Mechanical Valve

Short Description:

The HV series manual lever 4-port 3-position control mechanical valve from the pneumatic factory is a high-quality product designed for various pneumatic applications. This valve has precise control and reliable performance, making it suitable for use in industrial environments.



The HV series manual lever valve adopts a compact and ergonomic design, making it easy to operate manually. It is equipped with four ports, which can flexibly connect different pneumatic components. This valve adopts a three position control, which can accurately adjust the airflow and pressure.


Product Detail

Product Tags

Product Description

The HV series manual lever valves are manufactured by renowned pneumatic equipment manufacturers in pneumatic factories, ensuring durability and longevity. It is made of high-quality materials and can withstand harsh operating conditions, ensuring reliable performance even in harsh environments.



This type of mechanical valve is widely used in various industries such as automation, manufacturing, and assembly. It can be applied to pneumatic systems that control cylinders, actuators, and other pneumatic devices. The HV series manual lever valves can be seamlessly integrated into existing pneumatic settings, making them a versatile choice for different applications.

Technical Specification

Model

HV-02

HV-03

HV-04

Working Media

Compressed Air

Action Mode

Manual control

Port Size

G1/4

G3/8

G1/2

Max.Working Pressure

0.8MPa

Proof Pressure

1.0Mpa

Working Temperature Range

0~60℃

Lubrication

No Need

Material

Body

Aluminum Alloy

Seal

NBR
