CDU Series aluminum alloy acting multi position type pneumatic standard air cylinder

Short Description:

CDU series aluminum alloy multi position pneumatic standard cylinder is a high-performance pneumatic device. The cylinder is made of aluminum alloy material, with light weight and excellent corrosion resistance. Its multi position design enables it to move in different positions, providing greater flexibility and adjustability.

CDU series cylinders use standard pneumatic principle to drive the cylinder movement through compressed air. It has reliable performance and stable operation, and is suitable for various industrial automation applications. The cylinder is compact and easy to install, and can be seamlessly integrated with other equipment and systems.

One of the advantages of CDU series cylinders is its highly reliable sealing performance. It uses high-quality seals to ensure that the cylinder will not leak during operation. At the same time, the cylinder also has high wear resistance and can maintain good working condition after long-term use.

Send email to us

Product Detail

Product Tags

Technical Specification

Bore Size(mm)	6	10	16	20	25	32
Acting Mode	Double acting
Working Media	Cleaned Air
Working Pressure	0.1~0.7Mpa(1~9kgf/cm²)
Proof Pressure	1.05Mpa(10.5kgf/cm²)
Temperature	-5~70℃
Buffering Mode	Rubber buffer
Port Size	M5					1/8”
Body Material	Aluminum Alloy

Bore Size(mm)	Standard Stroke(mm)	Magnetic Switch
6	5 10 15 20 25 30	D-A93
10	5 10 15 20 25 30
16	5 10 15 20 25 30 35 40 45 50
20	5 10 15 20 25 30 35 40 45 50
25	5 10 15 20 25 30 35 40 45 50
32	5 10 15 20 25 30 35 40 45 50
